Port Traffic Controls

Guaranteed Minimum Bandwidth (GMB)

Either of the following commands configures ports A1 through A5 with

bandwidth settings:

ProCurve(config)#int a1-a5 bandwidth-min output 2 3 30 10

10 10 15 20

ProCurve(eth-A1-A5)#bandwidth-min output 2 3 30 10 10 10

15 20

Displaying the Current Guaranteed Minimum Bandwidth

Configuration

This command displays the per-port GMB configuration in the running-config

file.

Syntax: show bandwidth output [ port-list ]

Without [port-list], this command lists the GMB configuration

for all ports on the switch. With [port-list], this command lists

the GMB configuration for the specified ports. This command

operates the same way in any CLI context. If the command

lists Disabled for a port, there are no bandwidth minimums

configured for any queue on the port. (Refer to the description

of the no form of the bandwidth-min output command on page

13-21.)

For example, to display the GMB configuration resulting from either of the

above commands:

ProCurve(config)# show bandwidth output a1-a5

Outbound Guaranteed Minimum Bandwidth %

Port Q1 Q2 Q3 Q4 Q5 Q6 Q7 Q8

---- -- -- -- -- -- -- -- --

A1 2 3 30 10 10 10 15 20

A2 2 3 30 10 10 10 15 20

A3 2 3 30 10 10 10 15 20

User-Configured

Minimum

A4 2 3 30 10 10 10 15 20

Bandwidth

A5 2 3 30 10 10 10 15 20

Settings

Figure 13-6. Example of Listing the Guaranteed Minimum Bandwidth

Configuration

13-24

HP ProCurve Management And Configuration Guide
