Monitoring and Analyzing Switch Operation
Traffic Mirroring
Configuration Steps
Not e s If mirroring has already been enabled on the switch, the Menu screens will
appear differently than shown in this section.
1. From the Main Menu, Select:
2. Switch Configuration...
3. Network Monitoring Port
Enable mirroring by
setting this parameter
to “Yes”.
Figure B-18. The Default Network Mirroring Configuration Screen
2. In the Actions menu, press
[E] (for Edit).
3. If mirroring is currently disabled for session 1 (the default), then enable
it by pressing the Space bar (or
[Y]) to select Yes.
4. Press the down arrow key to display a screen similar to the following and
move the cursor to the Monitoring Port parameter.
B-32
