Configuring for Network Management Applications

Using SNMP Tools To Manage the Switch

ProCurve(config)# show snmp-server

SNMP Communities

Community Name MIB View Write Access

---------------- -------- ------------

public Manager Unrestricted

Trap Receivers

Link-Change Traps Enabled on Ports [All] : All

Send Authentication Traps [No] : No

Address Community Events Sent Notify Type Retry Timeout

--------------------- --------------- ----------- ----------- ----- --------

15.28.333.456 guest All inform 3 15

Excluded MIBs

Snmp Response Pdu Source-IP Information

Selection Policy : Default rfc1517

Trap Pdu Source-IP Information

Figure 14-12. Example Showing SNMP Inform Option Enabled

Advanced Management: RMON

The switch supports RMON (Remote Monitoring) on all connected network

segments. This allows for troubleshooting and optimizing your network.

The following RMON groups are supported:

■ Ethernet Statistics (except the numbers of packets of different frame sizes)

■ Alarm

■ History (of the supported Ethernet statistics)

■ Event

The RMON agent automatically runs in the switch. Use the RMON

management station on your network to enable or disable specific RMON

traps and events. Note that you can access the Ethernet statistics, Alarm, and

Event groups from the ProCurve Manager network management software. For

more on ProCurve Manager, visit the ProCurve Networking web site at

www.procurve.com

Click on products index, then look for the ProCurve Manager topic under the

Network Manager bar.

14-28

HP ProCurve Management And Configuration Guide
