2
2. NAME OF EACH COMPONENT
Temporary stop switch
Presser switch
Start switch
Operation panel
Control box
Power switch
Hand pulley
Machine head
Thread stand
Feed base
Cloth cutting dial
Power switch (EU type)
• Hand pulley
The needle bar can be lifted or lowered by hand with the handpulley.
• Cloth cutting dial
The cloth cutting knife can be lifted or lowered by hand with the
cloth cutting dial. (When the power is turned OFF.)
Hand pulley
and cloth cutting knife
rotate in accordance
with the rotation of the sewing machine and the drive of the
cloth cutting knife.
Be careful not to allow your hands or the like to touch to
them during operation of the sewing machine.
(1) Names of the sewing machine main unit
To Next Page
