7
ENGLISH
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
(1) Lubricating the machine and how to lubricate
＊
Use JUKI New Defrix Oil No. 2.
■
Lubricating the arm oil tank
Lubricate arm tank
to such an extent of
approximately 80 %.
■
Lubricating the bed oil tank
4. PREPARATION BEFORE OPERATION
DANGER :
Be sure carry out the work while observing the following in order to protect against pinching of
hands, fingers and arms between the sewing machine and the bottom cover, which can result in
serious injury, when you raise the sewing machine from its home position.
• Be sure to lock the hinge stopper to firmly secure the sewing machine in its raised position.
* Read and check how to rise/return the sewing machine described on p.3 to p.5.
1) Raise the machine head.
2) Lubricate bed oil tank
up to the MAX. line.
3) Return the machine head to its home position.
To Next Page
