43
ENGLISH
(3) Changing the setting position of cloth
Setting position of cloth can be changed to the front side.
1) Set memory switch No. 11 to “1”.
Traveling amount to the front side is set by memory switch No. 29. (22 mm in the standard state
of delivery) Setting “0” to 64 mm (S/R types) or “0” to 54 mm (J/C/T types) can be performed.
However, if the amount is excessively large, looper thread may not be clamped.
It is also possible to perform the normal use by lowering the presser with the presser switch and
performing sewing with the start switch. However, the presser LED of the hand switch is always
put in the state of flashing on and off.
(5) Changing over the presser movement
It is possible that the presser returns to the set position while it is held lowered after completion of sewing.
(The presser returns to the set position while it is raised after completion of sewing in the standard state of
delivery.)
1) Set memory switch No. 23 to “1”.
2)
The presser is held lowered when the sewing machine is stopped during sewing with the temporary stop
switch or when the feed base returns to the set position with [RESET ] key.
(6) Changing over the counter (DOWN counting)
Set the count value and perform DOWN counting. It is possible to prohibit the start at the count value “0”.
■
Change-over to DOWN counter
1) Set memory switch No. 12 to 2.
2) When the count value becomes “0”, the display flashes on and off and the start switch is inoperative.
3) Press [RESET ] key and the count value returns to the initial value.
(State of standard delivery : initial value = 100)
In order to perform the start even when the count value becomes “0”, set memory switch No. 13 to “0”.
■
Setting the initial value of DOWN counter
It is necessary to set the initial value starting “Count DOWN” when using DOWN counter.
1) Press [COUNTER ] key to display the counter.
2) Press [RESET ] key to return the count value to the initial value.
The initial value has been set to 100 in the state of standard delivery.
3) Set the count value with [RIGHT ] key or [RIGHT ] key.
(7) Stop before cloth cut mode
The sewing can be temporarily stopped before performing the cloth cutting operation at the time of the
pattern sewing of cut-after knife data.
1) Set memory switch No. 24 to “1”.
The sewing machine once stops after sewing and cloth cutting operation is performed by again pressing
the start switch.
It is also possible to return the sering machine to the cloth set position without performing cloth cutting
operation by pressing [RESET ] key.
(4) Changing over the mode of the start switch
The presser comes down by the operation of the start switch only, and the sewing is continually performed.
1) Set memory switch No. 14 to “1”.
To Next Page
