57
ENGLISH
(15) Replacing the gas spring
1) Loosen and remove stopper screw
.
2) Hold with your both hands periphery ribs
located on the front side of machine bed, slowly
lift the sewing machine, and stop it at the lock
position of the intermediate section.
Do not hold feed base
and feed guide
shaft fixing base
.
3) Further, support periphery ribs
of the machine
bed with your left hand, hold grip
of the hinge
stopper section with your right hand, release the
lock, and slowly lift the sewing machine. When
the sewing machine starts lifting, set free the
hinge stopper section held with your right hand
and support the periphery ribs with your both
hands.
DANGER :
Be sure carry out the work while observing the following in order to protect against pinching of
hands, fingers and arms between the sewing machine and the bottom cover, which can result in
serious injury, when you raise or return the sewing machine from or back to its home position.
1. Be sure to hold the rib on the bed periphery when holding the sewing machine.
2. Be sure to lock the hinge stopper to firmly secure the sewing machine in its raised position.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of
the sewing machine.
To Next Page
