35
ENGLISH
(9) Needle throwing width of the right bottom of eyelet setting
• Needle throwing width of the right side of
the bottom of eyelet can be set.
•
Feed base is actuated with the needle
throwing to change the sewing width.
Set the width with [RIGHT ] key
or [RIGHT ]
key
. The width can be set within the range of 2.3
±1.0 mm for S type, 2.5 ± 1.0 mm for J type, 2.5 ±
1.0 mm for C type and 2.3 ± 1.0 mm for T type in the
increments of 0.1 mm.
(8) Left parallel section lengthwise compensation
Length from the bottom of eyelet to the left
side of parallel section can be adjusted.
Set the length with [RIGHT ] key
or [RIGHT ]
key
.
Setting can be performed
−
0.6 to 0.6 mm in the
increments of 0.1 mm.
(10) Needle throwing width of the left bottom of eyelet setting
• Needle throwing width of the left side of
the bottom of eyelet can be set.
•
Feed base is actuated with the needle
throwing to change the sewing width.
Set the width with [RIGHT ] key
or [RIGHT ]
key
. The width can be set within the range of 2.3
±1.0 mm for S type, 2.5 ± 1.0 mm for J type, 2.5 ±
1.0 mm for C type and 2.3 ± 1.0 mm for T type in the
increments of 0.1 mm.
(11) Needle throwing width setting
• Needle throwing width of the whole
buttonholing can be set.
•
Feed base is actuated with the needle
throwing to change the sewing width.
Set the width with [RIGHT ] key
or [RIGHT ]
key
. The width can be set within the range of 2.3
±1.0 mm for S type, 2.5 ± 1.0 mm for J type, 2.5 ±
1.0 mm for C type and 2.3 ± 1.0 mm for T type in the
increments of 0.1 mm.
(12) Number of stitches of the slant taper bar
Number of stitches of the slant section from
the taper bar to the parallel section can be set.
Set the number of stitches with [RIGHT ] key
or
[RIGHT ] key
.
Setting can be performed 2 to 30 stitches within the
range of number of stitches of the taper bar.
＋
−
Length
width
width
width
Number of stitches
To Next Page
