33
ENGLISH
9. COMPENSATION OF THE DATA
1) Confirm that sewing LED
has gone out.
When the LED lights up, press [READY ] key
to make it go out.
2) Display the pattern No. desired to be changed.
3) Press [DATA ] key
to display the data.
4) Press [LEFT ] key
or [LEFT ] key
to
display the data No. of the part desired to be
changed.
5) Press [RIGHT ] key
or [RIGHT ] key
and
re-set the respective data.
6) Press [READY ] key
to light up sewing LED
and the data are stored in memory.
When changing the pattern No. without
pressing [READY ] key
or turning OFF
the power, the data are not stored in memory.
It is necessary to set again the data.
7) When the memory switch No. 20 is equal to
“1”, change of setting the data in step 5) can be
prohibited.
The data No. is stated in 2-digit LED
and the example of the set value is stated in 4-digit LED
as
shown below. The setting range is stated in the respective sentences.
−
＋
Stitches of the respective
compensations as shown below
are expreseed by the stitches as
observed from the right side of
stitching.
Wrong side
of stitching
Right side
of stitching
(1) Knife position compensation
Correct the slip between the position of
knife and sewing position.
1) When the knife position in terms of the stitches
is desired to be placed in the rear side, set “
＋
”
(plus) value, and in the front side, set “
−
”
(minus) value.
2) Set the knife position with [RIGHT ] key
or
[RIGHT ] key
. Setting can be performed
−
0.7 to 0.7 mm in the increments of 0.1 mm.
(2) Number of stitches of sewing end compensation
Number of stitches of sewing end can be
increased at the same sewing pitch.
Set the number of stitches with [RIGHT ] key
or [RIGHT ] key
.
Setting can be performed as follows :
Without bartack ...
−
1 to 6 stitches
Taper bar ...
−
1 to 6 stitches
Straight bar ...
−
1 to 3 stitches
−
＋
To Next Page
