Error
Touch the Error button to show the 15 most recent errors/warnings since the printer was switched on.
Beware:
When the control unit is rebooted or switched off the error list will be cleared.
Note:
To view errors 7 to 15 touch the screen at the bottom, between numbers and scroll bar, and drag the
messages upwards. This will scroll them into view.
Note:
Behind the error message is a counter which indicates how many times the same error occurred one
after the other.
Fig. 9.16 Error-Warning list
Touch the Ok button to return to the Diagnostics-Printer menu.
Calibration [X18 / X72]
In this menu the printhead voltage calibration values can be set.
Beware:
The system could get disrupted once the calibration values are not properly set. The calibration
procedure should only be performed by qualified personnel of Korthofah BV or a local distributor,
which is designated by Korthofah BV.
Cancel
Touch the Cancel button to return to the Diagnostics main menu.
9.1.5 Diagnostics
Touch Diagnostics to enter the diagnostics menu in which various system checks can be performed.
Beware:
System Diagnostics should only be run when the system is paused. Only a trained service engineer
should run these tests.
