6.2.4 Ink set
The standard ink set consists of:
▪ For oil based inks: two (2) bottles with 200ml Kortho ink.
▪ For solvent based inks: four (4) bottles with 100ml Kortho ink.
▪ Five (5) pair protection gloves.
▪ Handling instruction.
6.3 Coding unit mounting options
6.3.1 Distance between front plate and product
Fig. 6.5 Distance between front plate and product
The maximum print distance, distance A in Fig. 6.5, is 5 mm. If the situation permits, keep the print distance
as small as possible for an optimum print quality.
Take precautions so that the product cannot damage the printhead enclosure or front plate.
CAUTION:
Make sure the location of the installation does not prevent people doing their job, there is
sufficient light present for operating the printer and for maintenance and that the location is
accessible for operating the printer and for maintenance.
