TECHNICAL DATA - TIGHTENING TORQUES FOR CHASSIS 131

Spoke nipple M3.5 3 Nm (2.2 lbf ft) –

Rear brake caliper screw M6 10 Nm (7.4 lbf ft)

Loctite

243™

Remaining nuts, chassis M6 15 Nm (11.1 lbf ft) –

Screw, ball joint of push rod on foot

brake cylinder

M6 10 Nm (7.4 lbf ft) –

Screw, bottom triple clamp M6 10 Nm (7.4 lbf ft) –

Screw, front brake disc M6 15 Nm (11.1 lbf ft)

Loctite

243™

Screw, rear brake disc M6 15 Nm (11.1 lbf ft)

Loctite

243™

Screw, rear sprocket M7 15 Nm (11.1 lbf ft)

Loctite

243™

Engine carrying screw M8 25 Nm (18.4 lbf ft) –

Nut, rim lock M8 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M8 30 Nm (22.1 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, front brake caliper M8 20 Nm (14.8 lbf ft)

Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, top triple clamp M8 25 Nm (18.4 lbf ft) –

Nut, swingarm pivot M10 45 Nm (33.2 lbf ft) –

Remaining nuts, chassis M10 50 Nm (36.9 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft) –

Screw, handlebar support M10 40 Nm (29.5 lbf ft)

Loctite

243™

Screw, top shock absorber M10 45 Nm (33.2 lbf ft) –

Front wheel spindle nut M12x1 40 Nm (29.5 lbf ft) –

Nut, rear wheel spindle M12x1 40 Nm (29.5 lbf ft) –

Nut, steering stem M20x1.5 10 Nm (7.4 lbf ft) –

Steering head nut M20x1.5 10 Nm (7.4 lbf ft) –
