13/BRAKE SYSTEM 55
Info
Clean up overflowed or spilt brake fluid immediately with water.
13.6Changing the front brake fluid
Warning
Skin irritation Brake fluid can cause skin irritation on contact.
– Avoid contact with skin and eyes, and keep out of the reach of children.
– Wear suitable protective clothing and goggles.
– If brake fluid gets into your eyes, rinse thoroughly with water and contact a doctor immediately.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
Info
Never user DOT 5 brake fluid! This is based on silicone oil and is colored purple. Oil seals and brake lines are not designed for
DOT 5 brake fluid.
Avoid contact between brake fluid and painted parts. Brake fluid attacks paint!
Use only clean brake fluid from a sealed container!
201174-10
– Move the brake fluid reservoir mounted on the handlebar to a horizontal position.
– Remove screws .
– Remove cover with membrane .
– Draw the used brake fluid out of the brake fluid reservoir using a syringe and fill in
new brake fluid.
Bleed syringe (50329050000) ( p. 145)
Brake fluid DOT 4 / DOT 5.1 ( p. 138)
201173-10
– Pull off dust cap and connect a conventional suction device (workshop equip-
ment).
– Loosen bleeder screw and draw out the used brake fluid.
Info
During suction, ensure that the brake fluid reservoir is always filled with a
sufficient amount of new brake fluid.
– Tighten the bleeder screw. Remove the suction device and attach the dust cap.
400379-10
– Add brake fluid to level .
Guideline
Dimension (brake fluid level below
top edge of container)
5 mm (0.2 in)
Brake fluid DOT 4 / DOT 5.1 ( p. 138)
– Position the cover with the membrane. Mount and tighten the screws.
– Activate the hand brake lever until you feel a firm pressure point.
Info
Clean up overflowed or spilt brake fluid immediately with water.
