KTM 50 SX 2010 User Manual

31/CARBURETOR 97
300891-11
– Mount the carburetor connection boot.
– Position and tighten hose clamp .
300890-11
– Mount fuel hose .
– Check the play in the throttle cable. ( p. 20)
– Carburetor - adjust the idle speed. ( p. 107)
18.4Installing the carburetor (50 SX Mini)
300903-10
– Attach throttle cable .
300902-11
– Position spring retainer .
– Position the throttle slide spring.
300901-11
– Position the throttle slide and throttle slide cover.
– Mount and tighten screw .
Guideline
Screw, throttle slide cover M5 3 Nm (2.2 lbf ft)
300900-11
– Mount the carburetor.
– Position and tighten hose clamp .
