30/ENGINE 64
14.1Removing the engine
– Remove the fuel tank. ( p. 42)
– Drain the coolant. ( p. 112)
– Jack up the motorcycle. ( p. 7)
– Remove the exhaust manifold. ( p. 38)
300618-10
– Loosen the hose clamps. Detach the radiator hoses.
300619-10
– Remove the cable binder.
– Disconnect plug-in connector .
300620-10
(50 SX Mini)
– Detach oil line of the oil pump.
– Close the oil line using a suitable object.
300662-10
– Remove screws .
– Take off the engine sprocket cover.
300621-10
– Remove connecting link of the chain.
– Remove the chain.
