05/EXHAUST 39
700512-01
– Remove screw .
– Remove screw .
700513-10
– Pull the main silencer off of the manifold at the rubber sleeve .
7.4Installing the main silencer
700513-01
– Position the main silencer.
– Mount the main silencer with the rubber sleeve .
– Mount the silentblock with the screw .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
700512-10
– Position the collar sleeves.
– Mount and tighten screw .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
7.5Removing the glass fiber yarn filling of the main silencer
Warning
Danger of burns The exhaust system gets very hot when the vehicle is driven.
– Allow the exhaust system to cool down. Do not touch hot components.
– Remove the main silencer. ( p. 38)
700514-01
– Remove screws of locking cap . Remove locking cap and outer tube .
– Pull the glass fiber yarn filling from the inner tube.
– Clean the parts that are to be reinstalled.
