30/DISASSEMBLING THE ENGINE 71
300476-10
– Remove distance sleeve .
300477-10
– Mount special tool  on the rotor, apply counterpressure, and pull off the rotor
by screwing in the screw.
Extractor (46129021000) ( p. 144)
300853-10
(50 SX)
– Hold the rotor in place with special tool .
Holding spanner, rotor (45229012000) ( p. 143)
– Remove nut  and the washer of the rotor.
300854-10
– Mount special tool  on the rotor, apply counterpressure, and pull off the rotor
by screwing in the screw.
Extractor (46129021000) ( p. 144)
15.13Removing the engine sprocket
300479-10
– Remove lock ring . Take off the engine sprocket.
