30/DISASSEMBLING THE ENGINE 73
15.19Removing the kickstarter gear
301063-10
– Remove kickstarter gear .
15.20Removing the kickstarter idler shaft
300489-10
– Remove kickstarter idler shaft .
15.21Loosening the nut of the primary gear
300492-10
– Hold the clutch in place with special tool .
Gear segment (45229081000) ( p. 143)
– Loosen nut .
15.22Removing the centrifugal force clutch
300491-10
– Take off centrifugal force clutch  completely.
15.23Removing the kickstarter shaft
300493-10
– Remove kickstarter shaft  with the washer.
Info
The washer usually sticks to the bearing.
– Remove kickstarter spring .
