08/MASK, FENDER 44
10.1Dismounting the front fender
700479-10
– Remove screws . Remove the front fender.
10.2Installing the front fender
700480-01
– Position the fender with holding lugs  into the drill holes on the start number
plate.
700479-11
– Position the front fender. Mount and tighten screws .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
10.3Dismounting the start number plate
700466-01
– Remove screw  and take off clamp.
– Remove screw . Remove the start number plate.
10.4Installing the start number plate
700467-01
– Position the start number plate with the drill holes onto the holding lugs  of the
fender.
