12817 0x3211 DC bus overvoltage warning Keypad display: Warn.DC Bus OV
Cause Error type/response Remedy
DC-bus voltage has exceeded the warning
threshold for overvoltage set in 0x2540:005
(P208.05) due to a too high braking energy or a
too high mains voltage.
Warning
•
Reduce dynamic performance of the load
prole.
•
Check mains voltage.
•
Check sengs for brake energy manage-
ment.
•
Connect brake resistor to the power unit and
acvate the integrated brake chopper.
Related topics
4Mains voltage ^ 144
4Brake energy management ^ 443
12832 0x3220 DC bus undervoltage Keypad display: DC Bus UV
Cause Error type/response Remedy
DC-bus voltage has fallen below the error
threshold for undervoltage. The error threshold
(display in 0x2540:003 (P208.03)) results from
the seng of the rated mains voltage in
0x2540:001 (P208.01).
Trouble
•
Check mains voltage.
•
Check DC-bus voltage.
•
Check mains sengs.
Related topics
4Mains voltage ^ 144
12833 0x3221 DC bus undervoltage warning Keypad display: Warn.DC Bus UV
Cause Error type/response Remedy
DC-bus voltage has fallen below the warning
threshold for undervoltage set in 0x2540:002
(P208.02).
Warning
•
Check mains voltage.
•
Check DC-bus voltage.
•
Check mains sengs.
Related topics
4Mains voltage ^ 144
12834 0x3222 DC-bus voltage too low for switch-on Keypad display: DC-bus on-UV
Cause Error type/response Remedy
The input voltage is too low to switch on the
inverter.
Warning
•
Check mains voltage.
•
Check mains sengs.
Related topics
4Mains voltage ^ 144
16912 0x4210 PU: overtemperature fault Keypad display: PU Overtemp.
Cause Error type/response Remedy
The heatsink temperature of the power unit
(display in 0x2D84:001 (P117.01)) has exceeded
the xed error threshold (100 °C).
•
Ambient temperature too high.
•
Fan or venlaon slots are polluted.
•
Fan is defecve.
Fault
•
Provide for a sucient cooling of the device.
•
Clean fan and venlaon slots.
•
If required, replace fan.
•
Reduce switching frequency in .
Appendix
Error codes
643
