17024 0x4280 Thermal sensor heatsink error Keypad display: Heatsink sensor
Cause Error type/response Remedy
Sensor for the temperature monitoring of the
power unit is defecve. The failure of the tem-
perature monitoring funcon poses the risk of
overheang!
Fault Hardware error: it is necessary to contact the
manufacturer, since the device must be
replaced.
17025 0x4281 Heatsink fan warning Keypad display: Heatsink fan
Cause Error type/response Remedy
Warning of the heatsink fan. Warning Check/replace the heatsink fan.
17029 0x4285 Power secon overtemperature warning Keypad display: Warn.PU Overtemp
Cause Error type/response Remedy
The heatsink temperature of the power unit
(display in 0x2D84:001 (P117.01)) has exceeded
the warning threshold set in 0x2D84:002.
•
Ambient temperature too high.
•
Fan or venlaon slots are polluted.
•
Fan is defecve.
Warning
•
Provide for a sucient cooling of the device.
•
Clean fan and venlaon slots.
•
If required, replace fan.
•
Reduce switching frequency in .
Related topics
4Heatsink Temperature Monitoring ^ 137
17168 0x4310 Motor overtemperature error Keypad display: Overtemp. motor
Cause Error type/response Remedy
The motor temperature sensor connected to
terminals X109/T1 and X109/T2 measures a too
high motor temperature.
•
Motor too hot by impermissibly high cur-
rents.
•
Motor too hot by frequent and too long
acceleraon processes.
Fault
•
The error can only be reset aer a blocking
me of 5 s.
•
The error type can be congured in
0x2D49:002 (P309.02).
•
Check drive dimensioning.
•
Check motor temperature sensor and wiring.
Related topics
4Motor temperature monitoring ^ 219
20754 0x5112 24 V supply crical Keypad display: 24V supply low
Cause Error type/response Remedy
24V voltage failed or too low. Warning
•
Check oponal external 24V voltage supply
(terminal X3/24E), if connected.
•
Check mains voltage.
20864 0x5180 24-V supply overload Keypad display: Overlaod 24V
Cause Error type/response Remedy
Output current at the 24V output or at the digi-
tal outputs too high.
Warning Check 24V output and digital outputs for earth
fault or overload.
Appendix
Error codes
644
