INBOARD (MIE) MODELS
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 2B-3
NOTICE
For information and procedures on Troubleshooting, refer to SECTION 1C.
Torque Specifications
Description Nm lb-in. lb-ft
Coupler to Flywheel 34 25
Transmission Flange to Flywheel Housing 68 50
Trunnion Clamp Bolt 68 50
Front Engine Mount Bracket to Engine Block 75 55
Transmission Mount Bracket to Transmission Housing 75 55
Rear Engine Mount Rubber Bushing Center Bolt 61 45
Engine Mount Locking (Jam) Nuts 80 59
Transmission Output Flange to Propeller Shaft Coupler
Bolts
68 50
Remote Control Throttle and Shift Cable Barrel
Attaching Nut
Securely
Remote Control Throttle and Shift Cable End Guide
Attaching Nut
Tighten Nut Until It
Contacts Flat Washer;
then, Back Nut Off 1/2
Turn
Lubricants/Sealants/Adhesives
Description Part Number
Liquid Neoprene 92-25711-3
Battery Terminal Sealant Obtain Locally
