MAINTENANCE
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 1B-5
Inboard (MIE) Engines
Specification - Inboard (MIE)
Description
D2.8L D-Tronic D4.2L D-Tronic
Crankshaft Kilowatts (Horsepower)
1
123 ( 165 ) 186 ( 250 )
Propeller Shaft Kilowatts (Horsepower)
1
119 ( 160 ) 179 ( 240 )
Engine Type
In-Line 4 Cylinder
Diesel
In-Line 6 Cylinder
Diesel
Displacement
2.8 liter
169 cu. in.
4.2 liter (254 cu. in.)
Firing Order 1 - 3 - 4 - 2 1 - 5 - 3 - 6 - 2 - 4
Bore 94 mm ( 3.700 in. )
Stroke 100 mm ( 3.937 in. )
Compression Ratio 16.5:1
Valve Clearance - Intake / Exhaust Hydraulic
Maximum Pressure Difference Between
Cylinders
500 kPa ( 72 psi )
Maximum High Idle No Load rpm 4200 ± 50
Governed rpm Setting (Begins At:) 3850 ± 50
Rated rpm at Wide Open Throttle
2
3800
700
3
Low Idle rpm
600
4
750 rpm 1.5 - 3.1 bar ( 152-310 kPa ) [ 22-45 psi ]
Oil Pressure:
3800 rpm 3.5 - 5.6 bar ( 345-556 kPa ) [ 50-80 psi ]
Oil Temperature
100 - 110 degrees C
( 212 - 230 degrees F )
Water: ( 2 Total )
1 at temperature:
70 degrees C ( 160 degrees F )
Thermostats:
1 at temperature: 82 degrees C ( 180 degrees F )
Oil: ( 1 Total ) 95 degrees C ( 203 degrees F )
Coolant Temperature 80 - 85 degrees C ( 176 - 185 degrees F )
Electrical System 12-volt Negative ( – ) Ground
Alternator Rating 949W, 14.6v, 65 Amp.
Recommended Battery Rating 750 cca / 950 mca / 180 Ah
Starter 12v, 2.7 kW
1
Power rated in accordance with NMMA Procedure - ISO 3046 (Technically Identical to ICOMIA
28-83).
2
Refer to “Conditions Affecting Operation - Propeller Selection” for additional information.
3
Mercury Serial Number 0L343084 and Below on D2.8L D-Tronic Engines. Mercury Serial Number
0L343703 and Below on D4.2L D-Tronic Engines.
4
Mercury Serial Number 0L343085 and Above on D2.8L D-Tronic Engines. Mercury Serial Number
0L343704 and Above on D4.2L D-Tronic Engines.
