CHARGING SYSTEM SERVICE MANUAL NUMBER 22

Page 4B-20 90-860074--1 FEBRUARY 2002

Battery Isolator Diagram

72934

BB21

BLK

B +

(–)

RED

Typical Alternator

a-Isolator

b-Alternator

c-Starter

d-Cranking Battery

e-Auxiliary Battery

1-BLUE Wire From Alternator Battery Terminal

2-8 Gauge Minimum

Sufficient Gauge Wire Spliced To Connect As Shown.
