MAINTENANCE SERVICE MANUAL NUMBER 22
Page 1B-42 90-860074--1 FEBRUARY 2002
Drive Shaft Extension Models
1. Apply 3-4 pumps of U-joint And Gimbal Bearing Grease to drive shaft grease fittings.
71346
71347
a
b
a-Transom End Fittings
b-Engine End Fittings
Sterndrive Unit and Transom Assembly
1. Apply approximately 8-10 pumps of U-joint And Gimbal Bearing Grease to the gimbal
bearing.
70558
a
a-Gimbal Bearing
b-Hinge Pins
To Next Page
