ENGINE MECHANICAL SERVICE MANUAL NUMBER 22
Page 3A-14 90-860074--1 FEBRUARY 2002
Engine Specifications (continued)
NOTICE
UNIT OF MEASUREMENT: mm (in.)
Valve Guide
Valve Guide Exhaust Intake
Maximum Clearance
0.093 ( .0036 ) 0.073 ( .0028 )
Height Above Spring
Counterbore
7.921 - 7.939 (.311 - .312) 7.940 - 7.960 (.312 - .313)
Valve Spring
Valve Spring Height Pressure
Free Standing 44.65 (1.757) 0.0 kg (0 lb)
Valve Closed 38.60 (1.460) 32 - 36 kg (71 - 79 lb)
Valve Open 28.20 (1.110)
92.5 - 96.2 kg
(204 - 212 lb)
