ENGINE MECHANICAL
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 3A-19
General Information
Some repairs, that are listed in this section, must be completed with engine removed from
boat. Engine removal depends upon type of repair and boat design. Place engine on repair
stand for major repairs.
NOTE: This section contains disassembly and assembly procedures of the cylinder block
and cylinder heads only. Refer to other sections for disassembly and assembly of various
other components.
IMPORTANT: Do NOT use any sealers or adhesives containing silicone. Silicone can
cause blockage in the cooling/heat exchanger systems.
Engine Rotation
NOTE: Engine rotation is described when observed from the rear of the engine
(transmission end) looking forward (water pump end).
75303
Left-hand Rotation - All Models
Engine Firing Order
1234
56 1234
D2.8L D-TRONIC D4.2L D-TRONIC
Firing Order: 1-3-4-2 Firing Order: 1-5-3-6-2-4
