MAINTENANCE SERVICE MANUAL NUMBER 22

Page 1B-38 90-860074--1 FEBRUARY 2002

Inspect Water Pickups

SternDrive Gear Housing

1. Ensure that the gear housing water inlet holes are clean and not obstructed.

73186

Typical

a-Water Inlet Holes

Inboard Though the Hull Pickup

1. Ensure that the seawater pickup water inlet holes (slots) are clean and not obstructed.

70355

Typical

a-Water Inlet Holes (Slots)
