WIRING DIAGRAMS
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 4E-3
Wire Color Abbreviations
BLK Black PUR or PPL Purple
BLU Blue RED Red
BRN Brown TAN Tan
GRY Gray WHT White
GRN Green YEL Yellow
ORN Orange LIT or LT Light
PNK Pink DRK Dark
Special Tools
Description Part Number
DMT 2000A Tachometer / Multi-Meter
Kit
91-854009A3
Tools
Kent-Moore Tools
Kent-Moore Tools, Inc.
29784 Little Mack
Roseville, MI 48066
Phone: (313) 774-9500
Description Part Number
DVOM J-34029-A or Equivalent
Lubricants / Sealants / Adhesives
Description Part Number
Liquid Neoprene 92-25711--2
General Information
NOTE: If using other than Quicksilver instrumentation and harnesses, refer to
manufacturers’ instructions.
