ENGINE MECHANICAL
SERVICE MANUAL NUMBER 22
90-860074--1 FEBRUARY 2002 Page 3A-103
6. Remove lifters, being certain to keep them in order.
75383
75103
a
b
c
d
a-Push Rod
b-Retainer
c-Lifter
d-Roller
Cleaning
1. Wash all parts in cleaning solvent.
2. Dry with compressed air.
Inspection
1. Inspect lifters carefully. If any parts are damaged or worn, the entire lifter assembly
should be replaced. Refer to Specifications.
2. If outer lifter body wall is scuffed or worn, inspect cylinder block lifter bore.
3. If roller is worn or damaged, inspect camshaft lobe.
4. If push rod seat is scuffed or worn, inspect push rod.
