ENGINE MECHANICAL

SERVICE MANUAL NUMBER 22

90-860074--1 FEBRUARY 2002 Page 3A-3

Identification

75298

7332

75388

MARINE POWER

EUROPE INC

MADE IN ITALY

SERIAL NUMBER

MAX

RPM

Typical Sterndrive (MCM) Engine Shown - Inboard (MIE) Similar

a-Serial Number Plate

b-Manufacturer’s Serial Number

The engine model and serial numbers are located on a sticker attached to the port side of

the engine. The manufacturer’s serial number is stamped in the cylinder block.
