4.14
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
FUEL TANK INSTALLATION
1. Reinstall the fuel tank into the chassis taking care not
to damage brake lines or the wire harness.
2. Install (3) plastic tie straps to retain the wire harness
to the fuel tank.
3. Install fuel tank brackets and (2) fasteners retaining
fuel tank to chassis. Torque fasteners to
specification.
TORQUE
Fuel Tank Bracket Fasteners:8 ft-lbs (11 Nm)
4. Reconnect the fuel pump electrical harness.
5. Install the fuel line and vent line, and verify they are
secure.
6. Install the main floor.
7. Reconnect the negative battery cable. Test the fuel
pump by turning on the key and listening for the
pump to activate.
8. Install storage bins and driver and passenger seat
bases.
FUEL SYSTEM - GENERAL
