FRONT GEARCASE - CENTRALIZED HILLIARD
CENTRALIZED HILLIARD EXPLODED VIEW
REF# DESCRIPTION
QTY
REF# DESCRIPTION
QTY
1 Pinion Gear 1 17
Hub Assembly
2
2
O-Ring
1 18 Rollers 20
3 Dowel Pin 1 19
Torsion Spring
1
4
Vent Hose Fitting
1 20
Spring, Wireform
2
5
Ball Bearing
2 21
H-Clip Spring
20
6
Ball Bearing (Double Row)
1 22
Connector Assembly
1
7
Bushing
1 23
Nylon Spacer
2
8
Bushing
1 24
Torsion Spring Retainer
1
9 Oil Seal 2 25
Backlash Spacer
1
10 Oil Seal 1 26 Armature Plate 1
11
Retaining Ring, Internal
1 27 AWD Coil 1
12
Cover Screws, M6 (T30 Torx)
7 28 Grommet 1
13
Cover Plate Assembly
1 29
Fill Plug
1
14
Gearcase Housing
1 30
Drain Plug, Magnetic
1
15
Clutch Housing (Ring Gear)
1 31
Retaining Ring, External
1
16
Roll Cage
1
FINAL DRIVE
