6
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
6.3
SPECIAL TOOLS AND SUPPLIES
TOOL DESCRIPTION
PART
NUMBER
Clutch Bushing Replacement
Tool Kit
2871025
Clutch Bushing Replacement
Tool Kit
2871226
Clutch Holding Fixture
2871358-A
Drive Clutch Holding Tool
9314177-A
Drive Clutch Puller 2872085
Drive Clutch Spider Removal and
Installation Tool
2870341
Piston Pin Puller 2870386
Roller Pin Tool 2870910
Universal Clutch Compressor
PU-50518
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com
SPECIAL SUPPLIES
PART
NUMBER
Loctite® 648 and 263 n/a
RTV Silicone Sealer n/a
TORQUE SPECIFICATIONS
PVT SYSTEM FASTENER TORQUES
ITEM
TORQUE VALUE
Drive Clutch Cover Bolts
100 in-lbs (12 Nm)
Drive Clutch Retaining Bolt 96 ft-lbs (130 Nm)
Drive Clutch Spider
(Apply 263 Loctite®)
290 ft-lbs (393 Nm)
Driven Clutch Retaining Bolt 38 ft-lbs (52 Nm)
PVT Inner Cover Bolts
10 ft-lbs (14 Nm)
PVT Outer Cover Screws
54 in-lbs. (6.1 Nm)
Shift Weight Fasteners (Nuts) 20 in-lbs. (2.3 Nm)
CLUTCHING
