5
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
5.47
REMOVAL / INSTALLATION
1. Elevate and safely support the vehicle with weight
removed from the rear wheel(s).
2. Using a 13mm socket, remove the (4) nuts retaining
the stabilizer bar to the frame.
3. Using a 15mm socket, remove the upper stabilizer
bar linkage nut on each side.
4. Remove the stabilizer bar from the frame and inspect
the stabilizer bar for straightness.
5. Reverse this procedure for installation.
6. Torque the stabilizer bar mounting bolts and upper
rubber linkage bushing nuts to specification.
TORQUE
Stabilizer Bar to Frame:
17 ft-lbs (23 Nm)
TORQUE
Stabilizer Bar Linkage Bushing:
17 ft-lbs (23 Nm)
BODY / STEERING / SUSPENSION
