5
9924880 Rev 2- 1/10/2014 - 2013 / 2014 RANGER XP 900 - 2014 RANGER XP 900 / CREW 900 Service Manual
© Copyright Polaris Sales Inc.
5.3
TORQUE SPECIFICATIONS
ITEM
TORQUE VALUE
FT-LBS (NM)
A-arm to Frame Bolts
40 ft-lbs (54 Nm)
A-arm to Bearing Carrier
Bolts
40 ft-lbs. (54 Nm)
Ball Joint Pinch Bolts
42 ft-lbs (57 Nm)
Cab Frame Bolts 30 ft-lbs (41 Nm)
Cab / Seat Base Bolts 14 ft-lbs (19 Nm)
Cargo Box Latch Bolts 17 ft-lbs (23 Nm)
Cargo Box Support Bolts 14 ft-lbs (19 Nm)
EPS Unit Mounting Bolts 30 ft-lbs (41 Nm)
EPS Unit Mount Bracket
Bolts
14 ft-lbs (19 Nm)
Floor Support Bolts 30 ft-lbs (41 Nm)
Front Bumper Bolts
30 ft-lbs. (41 Nm)
Grab Handle Bolts 14 ft-lbs (19 Nm)
Hip Bolster Bolts (Upper) 8 ft-lbs (11 Nm)
Hip Bolster Bolts (Lower) 14 ft-lbs (19 Nm)
Headrest Bolts
8 ft-lbs (11 Nm)
Lower Steering Shaft
Upper Pinch Bolt (EPS)
15 ft-lbs (20 Nm)
Lower Steering Shaft
Lower Pinch Bolt (EPS)
40 ft-lbs (54 Nm)
Pivot Tube Mounting Bolts
18 ft-lbs (24 Nm)
Rear Cab Support Bolts 30 ft-lbs (41 Nm)
Rocker Support Bolts 8 ft-lbs (11 Nm)
Seat Belt Mounting Bolts 40ft-lbs (54 Nm)
Shock Mounting Bolts 40 ft-lbs (54 Nm)
Side Net Bolts 8 ft-lbs (11 Nm)
Skid Plate Bolts 8 ft-lbs (11 Nm)
Stabilizer Bar to Frame 17 ft-lbs (23 Nm)
Stabilizer Bar
Linkage Bushings
17 ft-lbs (23 Nm)
Steering Gearbox Bolts 16 ft-lbs (22 Nm)
Steering Shaft Pinch Bolt
(Non-EPS)
40 ft-lbs (54 Nm)
ITEM
TORQUE VALUE
FT-LBS (NM)
Steering Wheel Nut 65 ft-lbs (88 Nm)
Tie Rod to Steering Knuckle
Mounting Bolts
40 ft-lbs (54 Nm)
Tie Rod End Jam Nut
14 ft-lbs (19 Nm)
Tilt Shock Mounting Bolts 7 ft-lbs (10 Nm)
Upper Steering Shaft
Pinch Bolt (EPS)
15 ft-lbs (20 Nm)
Wheel Hub Castle Nut
(Front)
75 ft-lbs (102 Nm)
Wheel Hub Castle Nut
(Rear)
110 ft-lbs (149 Nm)
Wheel Nuts (Steel Rim) 60 ft-lbs (81 Nm)
Wheel Nuts (Aluminum Rim) 120 ft-lbs (163 Nm)
NOTE
Refer to exploded views throughout this chapter for
more torque specifications, component identification,
and location of components.
BODY / STEERING / SUSPENSION
