SPECIFICATIONS
TORQUE SPECIFICATIONS
ITEM
TORQUE VALUE
Bearing Retaining
Plate Screws
8-10 ft-lbs (11-14 Nm)
Bellcrank Nut
12-18 ft-lbs (16-24 Nm)
Fill / Drain Plugs 10-14 ft-lbs (14-19 Nm)
Gear Sector Cover
9-12 ft-lbs (12-16 Nm)
Park Flange Screws 8-10 ft-lbs (11-14 Nm)
Rear Transmission Isolator
Mount Bolt
22 ft-lbs (30 Nm)
Rear Transmission
Mount Bolt
40 ft-lbs (54 Nm)
Shift Fork
Retaining Screws
7-10 ft-lbs (10-14 Nm)
Snorkel Tube
Refer to “Snorkel Gear
Backlash Procedure”
Snorkel Tube
Locking Screw
8-10 ft-lbs (11-14 Nm)
Differential Solenoid
25 ft-lbs (34 Nm)
Transmission Case
Screws
15-20 ft-lbs (20-27 Nm)
Speed Sensor Screw 9-12 ft-lbs (12-16 Nm)
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
PA-50231 Snorkel Tool
2871698
(Part of 2871702 Kit)
Rear Output Seal Driver
2871699
(Part of 2871702 Kit)
Rear Driveshaft Seal Guide
2871282
Bearing Seal Driver (50 mm)
PU-50658 Clutch Center Distance Tool
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com
LUBRICATION
FLUID CAPACITY
Recommended Transmission Lubricant:AGL(PN
2878068) (Quart)Capacity: 41 oz. (1200 ml)
