Scalar DLC Reference Guide 201
Traps
SNMP Traps
Trap is a message sent by an agent to a management system indicating that an event has occurred on the
host running the agent. For example, the SNMP service can be configured to send a trap when it receives
a request for information that does not contain the correct community name and does not match an
accepted host name for the service.
Stop SNMP Click Stop SNMP service (active when SNMP service is started).
Help Click Open online help for the current pane.
Field/Button Icon Operation Description
Community name Enter/Select Community to send traps.
Add Click Add new Trap community
Remove Click Remove community from list.
Trap destinations Click to
select
Current trap destinations
Add Click Add new trap. Pop-up SNMP Service Configuration dialog
opens, see Figure 142
on page 202.
Field/Button Icon Operation Description
