Scalar DLC Reference Guide 227
Figure 170 Group Level
Figure 171 Class Level
Remove Click Removes the objects from tracing list.
Level Click Chooses the sensitivity level for the tracing current object. See
Figure 174
on page 228.
Start Click Start the tracing. See Figure 175
on page 229.
Stop Click Stop the tracing.
Update Click Save the current trace manager options as default.
Options Click Show the trace manager options pane. See Figure 176
on
page 229.
Exit Click Close the pane without saving the changed options.
List Operation Description
Group Supplied Group name.
Level Select The sensitivity level where one is minimum and five is maximum.
OK Click Save the options and exit this pane.
Cancel Click Close the pane without saving the changed options.
List Operation Description
Class Supplied Class name.
Level Select The sensitivity level where one is minimum and five is maximum.
OK Click Saves the options and exit this pane.
Cancel Click Closes the pane without saving the changed options.
Field/Button Operation Description
