30—VGA Main Display Universal Elements
Roland VS-2400CD Owner’s Manual www.RolandUS.com 393
5. Automix Controls
6. UNDO/REDO
7. EXT SYNC
8. Metronome
9. A.PUNCH
10. LOOP
Click:
•
AUTOMIX
—to turn the Automix feature on or off.
•
Automix Record
—to start or stop recording Automix data.
•
SNAPSHOT
—to take a snapshot of your mixer settings at the now
line’s current mixer location.
•
Automix Undo/Redo
—to undo or redo your most recent Automix
action.
Click UNDO to reverse your last recording or editing action. If the
REDO light on the VS-2400CD is lit, click REDO to restore your latest
undone action.
Click EXT SYNC so it lights to synchronize the VS-2400CD to an
external device according to the current UTILITY menu Sync parameter
settings.
Click the Metronome button to turn the VS-2400CD’s metronome
on or off by changing the setting of the METRONOME OUT
parameter. The parameter can be set to Off, INT (yellow) or MIDI
(blue).
Click A.PUNCH to display the AUTO PUNCH/LOOP window in which
you can set punch in and -out points. If punch points have been set,
click this button turn on the VS-2400CD’s Auto Punch feature.
Punch-in and -out points appear above the Home screen’s playlist as red arrows. When
Auto Punch is turned on, a red bar connects the two points. See Page 406.
Click LOOP to display the AUTO PUNCH/LOOP window in which you
can set loop start and end points. If the loop points have been set, click
this button to turn on looped playback of the VS-2400CD’s hard disk
recorder.
Loop start and end points appear above the Home screen’s playlist as blue arrows.
When looping is turned on, a blue loop box connects the two points. See Page 406.
SNAPSHOTAUTOMIX
Automix Record Automix Undo/Redo
UNDO REDO
