Siemens SINUMERIK 828D Programming Manual

Flexible NC programming
1.12 Check structures
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
105
1.12.6 Program example with nested check structures
Program code Comments
LOOP
IF NOT $P_SEARCH ; No block search
G01 G90 X0 Z10 F1000
WHILE $AA_IM[X] <= 100
G1 G91 X10 F500 ; Hole drilling template
Z–F100
Z5
ENDWHILE
Z10
ELSE
MSG("No drilling during block search")
ENDIF
$A_OUT[1] = 1 ; Next drilling plate
G4 F2
ENDLOOP
M30
