Siemens SINUMERIK 828D Programming Manual

Flexible NC programming
1.10 Program jumps and branches
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
89
Example 4: Jump with jump condition
Program code Comments
N40 R1=30 R2=60 R3=10 R4=11 R5=50 R6=20 ; Assignment of the initial values.
N41 LA1: G0 X=R2*COS(R1)+R5 Y=R2*SIN(R1)+R6 ; Jump marker LA1 set.
N42 R1=R1+R3 R4=R4-1
N43 IF R4>0 GOTOB LA1 ; If the jump condition is
fulfilled, then a jump in the
direction of the beginning of the
program to jump marker LA1.
N44 M30 ; End of program
1.10.3 Program branch (CASE ... OF ... DEFAULT ...)
Function
The CASE function provides the possibility of checking the actual value (type: INT) of a
variable or an arithmetic function and, depending on the result, to jump to different positions
in the program.
Syntax
CASE(<expression>) OF <constant_1> GOTOF <jump destination_1>
<constant_2> GOTOF <jump destination_2> ... DEFAULT GOTOF <jump
destination_n>
Significance
CASE: Jump statement
<expression>: Variable or arithmetic function
OF: Keyword to formulate conditional program branches.
First specify constant value for the variable or arithmetic function
<constant_1>:
Type: INT
Second specified constant value for the variable or arithmetic
function
<constant_2>:
Type: INT
DEFAULT: For the cases where the variable or arithmetic function does not
assume any of the specified constant values, the DEFAULT
instruction can be used to determine the branch destination.
Note:
If the DEFAULT instruction is not programmed, then in these
cases, the block following the CASE instruction is the jump
destination.
