Axis couplings
9.4 Electronic gear (EG)
Job planning
532 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Version 3:
Syntax Description
EGOFC(following spindle1)
The electronic gear is deactivated. The following spindle
continues to traverse at the speed/velocity that applied at
the instant of deactivation. This call triggers a preprocessing
stop.
Note
This version is only permitted for spindles.
9.4.4 Deleting the definition of an electronic gear (EGDEL)
Function
An EG axis group must be switched-out before its definition can be deleted.
Programming
Syntax Significance
EGDEL(following axis)
The coupling definition of the axis group is deleted. Additional
axis groups can be defined by means of
EGDEF until the
maximum number of simultaneously activated axis groups is
reached. This call triggers a preprocessing stop.
9.4.5 Rotational feedrate (G95) / electronic gear (FPR)
Function
The FPR command can be used to specify the following axis of an electronic gear as the axis,
which determines the revolutional feedrate. Please note the following with respect to this
command:
● The feedrate is determined by the setpoint velocity of the following axis of the electronic
gear.
● The setpoint velocity is calculated from the speeds of the leading spindles and modulo
axes (which are not path axes) and from their associated coupling factors.
● Speed parts of linear or non-modulo leading axes and overlaid movement of the following
axis are not taken into account.
