Motion synchronous actions
10.3 Main run variables for synchronized actions
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
561
Examples of implicit type conversions
Type conversion from INTEGER to BOOL
$AC_MARKER[1]=561
ID=1 WHEN $A_IN[1] == TRUE DO $A_OUT[0]=$AC_MARKER[1]
Type conversion from REAL to BOOL
R401 = 100.542
WHEN $A_IN[0] == TRUE DO $A_OUT[2]=$R401
Type conversion from BOOL to INTEGER
ID=1 WHEN $A_IN[2] == TRUE DO $AC_MARKER[4] = $A_OUT[1]]
Type conversion from BOOL to REAL
R401 = 100.542
WHEN $A_IN[3] == TRUE DO $R10 = $A_OUT[3]
10.3.3 GUD variables
GUD variables capable of synchronized actions
As well as specific system variables, predefined global synchronized-action user variables
(synchronized action GUD) can also be used in synchronized actions. The number of
synchronized action GUD items available to the user is parameterized for each specific data
type and access using the following machine data:
● MD18660 $MM_NUM_SYNACT_GUD_REAL[<x>] = <number>
● MD18661 $MM_NUM_SYNACT_GUD_INT[<x>] = <number>
● MD18662 $MM_NUM_SYNACT_GUD_BOOL[<x>] = <number>
● MD18663 $MM_NUM_SYNACT_GUD_AXIS[<x>] = <number>
● MD18664 $MM_NUM_SYNACT_GUD_CHAR[<x>] = <number>
● MD18665 $MM_NUM_SYNACT_GUD_STRING[<x>] = <number>
