Flexible NC programming
1.1 Variables
Job planning
40 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
NOTICE
Compatibility of units
When using variables (assignment, comparison, calculation, etc.) the compatibility of the
units involved is not checked. Should conversion be required, this is the sole responsibility
of the user/machine manufacturer.
See also
General information about variables (Page 15)
1.1.10 Attribute: Access rights (APR, APW, APRP, APWP, APRB, APWB)
The following protection levels, which have to be specified during programming, correspond
to the access rights:
Access right Protection level
System password 0
Machine manufacturer password 1
Service password 2
End user password 3
Key-operated switch position 3 4
Key-operated switch position 2 5
Key-operated switch position 1 6
Key-operated switch position 0 7
Definition (DEF) of user variables
Access rights (APR.../APW...) can be defined for the following variables:
● Global user data (GUD)
