Coordinate transformation (FRAMES)
5.2 Frame variables / assigning values to frames
Job planning
290 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
5.2.2 Reading and changing frame components (TR, FI, RT, SC, MI)
Function
This feature allows you to access individual data of a frame, e.g., a specific offset value or
angle of rotation. You can modify these values or assign them to another variable.
Syntax
R10=$P_UIFR[$P_UIFNUM,X,RT]
Assign the angle of rotation RT around the X axis
from the currently valid settable zero offset
$P_UIFRNUM to the variable R10.
R12=$P_UIFR[25,Z,TR]
Assign the offset value TR in Z from the data
record of set frame no. 25 to the variable R12.
R15=$P_PFRAME[Y,TR]
Assign the offset value TR in Y of the current
programmable frame to the variable R15.
$P_PFRAME[X,TR] = 25
Modify the offset value TR in X of the current
programmable frame. X25 applies immediately.
Significance
$P_UIFRNUM This command automatically establishes the reference to the
currently valid settable zero offset.
P_UIFR[n,…,…] Specify the frame number n to access the settable frame no.
n.
Specify the component to be read or modified:
TR TR Translation
FI FI Translation Fine
RT RT Rotation
SC SC Scale scale modification
MI MI mirroring
X Y Z The corresponding axis X, Y, Z is also specified (see
examples).
Value range for RT rotation
Rotation around 1st geometry axis: -180° to +180°
Rotation around 2nd geometry axis: -90° to +90°
Rotation around 3rd geometry axis: -180° to +180°
