Tool offsets
7.2 Additive offsets
Job planning
392 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
7.2 Additive offsets
7.2.1 Selecting additive offsets (DL)
Function
Additive offsets can be considered as process offsets that can be programmed in the
machining. They refer to the geometrical data of a cutting edge and are therefore a
component of tool cutting data.
Data of an additive offset are addressed using a DL number (DL: Locationdependent; offsets
regarding the location of use) and entered via the operator interface.
Application
Dimension errors caused be the location of use can be compensated using additive offsets.
Syntax
DL=<number>
Significance
DL
Command to activate an additive offset
<number>
The additive tool offset data to be activated is specified using the
<number>
parameter.
Note
The machine data is used to define the number of additive offsets and also activate them
(→ carefully observe the machine OEM's data!).
