Siemens SINUMERIK 828D Programming Manual

Motion synchronous actions
10.4 Actions in synchronized actions
Job planning
Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
589
10.4.9 Online tool offset (FTOC)
Function
FTOC permits overlaid movement for a geometry axis after a polynomial programmed with
FCTDEF depending on a reference value that might, for example, be the actual value of an
axis.
The coefficient a
0
of the function definition FCTDEF(...) is evaluated for FTOC. Upper and
lower limit are dependent on a
0
.
FTOC can be used to program modal online tool offsets or clearance controls as synchronized
actions.
The function is used for the machining of a workpiece and dressing of a grinding wheel in the
same channel or in different channels (machining and dressing channel).
The general conditions and specifications for dressing grinding wheels apply for
FTOC in the
same way that they apply for online tool offset with
PUTFTOCF (see "Online tool offset
(PUTFTOCF, FCTDEF, PUTFTOC, FTOCON, FTOCOF) (Page
404)").
Syntax
FCTDEF(<function>,<LLimit>,<ULimit>,<a0>,<a1>,<a2>,<a3>)
FTOC(<function>,<reference value>,<tool parameter>,<channel>,<spindle>)
...
Significance
FCTDEF is used to define the polynomial function for FTOC.
Parameter:
Number of the polynomial function
Type: INT
<function>:
Range of values: 1 to 3
Lower limit value
<LLimit>:
Type: REAL
Upper limit value
<ULimit>:
Type: REAL
Coefficients of polynomial function
FCTDEF:
<a0> to <a3>:
Type: REAL
