Siemens SINUMERIK 828D Programming Manual

Special Motion Commands
4.4 NC block compression (COMPON, COMPCURV, COMPCAD, COMPOF)
Job planning
250 Programming Manual, 07/2010, 6FC5398-2BP40-0BA0
Example 2: COMPCAD
Program code Comment
G00 X30 Y6 Z40
G1 F10000 G642 ; Blending function G642 on.
SOFT ; Jerk limiting SOFT on.
COMPCAD ; Compressor function COMPCAD on.
STOPFIFO
N24050 Z32.499
N24051 X41.365 Z32.500
N24052 X43.115 Z32.497
N24053 X43.365 Z32.477
N24054 X43.556 Z32.449
N24055 X43.818 Z32.387
N24056 X44.076 Z32.300
…
COMPOF ; Compressor function off.
G00 Z50
M30
References
Function Manual, Basic Functions; Continuous-Path Mode, Exact Stop, Look Ahead (B1),
Chapter: "NC block compression"
