Mounting and maintenance
4.6 System response for a modified hardware configuration
Power supply system SITOP PSU8600
Manual, 09.2018, A5E36758446-5-76
133
Response after adding an individual component
Adding involves expanding the system on the right-hand side by adding additional
components.
Note
When changing the module sequence, by checking the module position it is possible that
previously used modules are undesirably deactivated
– and outputs that have been used up
To avoid undesirably deactivating modules that hav
e been used up until now – and shutting
down outputs that have been used up until now, insert the new individual components at the
right
-hand side of the system. As a consequence, the previous module sequence in the
system configuration is not changed.
Response after adding a component and powering up in the MANUAL mode
● New buffer modules and UPS modules are automatically commissioned.
● For new expansion modules, after switching on again, the outputs are in the operating
state "manually shut down" (the LEDs of the outputs are lit yellow).
The outputs are switched-on by pressing their associated buttons.
Response after adding a component and powering up in the REMOTE mode
● The new module is deactivated (LED "O.K." flashes red, LEDs of the expansion module
outputs are dark).
You can activate the module by loading a correct configuration via the associated control
system.
